5 axis stone cutting machinery
For fabricators and sculptors seeking to push the boundaries of precision and complex geometry, a 5 axis stone cutting machine represents the pinnacle of digital stoneworking technology. Unlike traditional 3-axis machines, a true 5 axis stone cutting machine provides simultaneous movement along five distinct axes, allowing the cutting tool to approach the workpiece from virtually any angle. This capability is indispensable for creating intricate 3D sculptures, detailed architectural elements like ornate columns and capitals, complex countertop features, and seamless miters. The primary advantage of this advanced machinery lies in its ability to complete complex parts in a single setup, dramatically reducing production time, minimizing material handling, and eliminating errors associated with multiple fixturing. By integrating a high-performance 5 axis stone cutting machine into your workshop, you unlock new design possibilities, enhance product quality with flawless surface finishes, and significantly boost overall operational efficiency.
The **PrecisionMaster Pro-5000CNC** is engineered for industrial durability and sub-millimeter accuracy, making it suitable for both high-volume production runs and bespoke, one-of-a-kind artistic projects. Its robust cast-iron construction and vibration-dampening base ensure stable operation even during aggressive cutting of hard materials like granite and quartzite. The machine features a fully enclosed workspace with integrated dust and slurry extraction ports, maintaining a cleaner and safer shop environment. An intuitive, user-friendly CNC interface with offline programming support allows operators to easily import 3D models from popular CAD software, simulate tool paths to prevent collisions, and optimize cutting sequences for maximum material yield and tool life. The **PrecisionMaster Pro-5000CNC** is not just a tool; it is a comprehensive solution for modern stone fabrication.
Core Technical Specifications
- Control System: Siemens 840D sl CNC with 15" Touchscreen Interface
- Positioning Accuracy: ±0.01mm
- Repeated Positioning Accuracy: ±0.005mm
- Spindle Power: 18.5kW (25 HP) High-Frequency Electric Spindle
- Spindle Speed Range: 0 - 24,000 RPM
- Tool Holder: HSK-63F
- Automatic Tool Changer (ATC): 12-Station, Disc-Type
Working Envelope & Axes Specifications
| Axis | Travel (X, Y, Z) | Maximum Feed Rate | Drive System |
|---|---|---|---|
| X (Longitudinal) | 3000 mm | 30 m/min | Linear Guideways, Servo Motor |
| Y (Transverse) | 2000 mm | 30 m/min | Linear Guideways, Servo Motor |
| Z (Vertical) | 800 mm | 20 m/min | Linear Guideways, Servo Motor |
| A (Rotary - Tilting) | ±110° | 15 RPM | Direct-Drive Torque Motor |
| C (Rotary - Continuous) | 360° Continuous | 20 RPM | Direct-Drive Torque Motor |
